Flow Schematic

Specifications

Model Edi-Q10 Edi-Q10UT
Output(25°C)* 10 liters/hour
Pure water outlet 2: reverse osmosis water, deionized water
Edi water quality
Resistivity >5MΩ.cm
TOC* <30ppb
Silicone rejection rate >99.9%
Bacteria N/A <0.1cfu/ml
Particle(>0.1µm) N/A <1/ml
RO water quality
Ion rejection rate 96%-99% (new RO membrane)
Organic rejection rate >99%, when MW>200 Dalton
Particles and bacteria rejection rate >99%
Feed water requirements Tap water, temperature:5-45°C,pressure:1.0-4.0Kgf/cm2
Dimension and weight Length×Width×Height:500×360×540mm / Weight: about 20Kg
Electrical requirements AC110-240V, 50/60Hz
Power 120W
Standard configuration Main body (Including 1 set of cartridge)+20 liters PE tank
Remarks:
*The value will be influenced by temperature and feed water’s quality.
Edi-Q series can be upgraded to touch screen system, just the same as Master to Master Touch.
